STANDARD PROBES

3-, 5-, 7-Hole probes

To determine velocity and angle of attack, total pressure, and static pressure

Omniprobes

To determine the angle and velocity of a probe even in reverse flows

Pitot and Kiel probes

To determine the total pressure of a flow over a wide angle range

Prandtl probes

To determine static and total pressure or air speed and elevation



For inquiry contact us for a quote.

KIEL & RADIATOR PROBES

Specifications

Tip diameter starting at 1.6 mm

Multiple lengths available

Available materials: stainless steel, titanium, Inconel, high-temperature stainless steel and others

Fixture and connections to be determined by customer

Angle range up to ± 62°

Velocity range up to Mach 2

Temperature range up to 1000 °C

Integrated thermocouple option available



For inquiry contact us for a quote.

HIGH TEMPERATURE PROBES

Superalloys

Co-based alloys

Inconel 625; Inconel 718

Hastelloy X

PtRhxx and other PGM Materials > 1800°C

Ceramics > 1800°C

Refractory metals (non-oxidizing athmosphere)

Additive Manufacturing

Aerodynamically optimized shapes

One piece solid part solutions

Strength calculations

Optimized designs

Cooling

Integration of cooling channels



For inquiry contact us for a quote.

CUSTOMIZED PROBES

Temperature probes

All probes can be upgraded to measure the total temperature

Rakes

To determine the required quantity at multiple measurement points simultaneously

Kiel rakes (1D & for performance measurements)

Multi-hole probe rakes

Engine inlet distortion & stator rakes from high performance alloys



For inquiry contact us for a quote.

FAST RESPONSE MEASUREMENT PROBES

Our probes

Additive manufacturing allows almost any geometry Titanium, Inconel, stainless steel, plastics

Robust design

High temporal resolution pressure sensors integrated into the shaft

High spatial resolution

Frequency calibrated

Measurement frequencies up to 25 kHz

Full plug&play system including DAQ hardware

Applications

3D turbulence spectra

Time-resolved high frequency measurements

Shock events

Unsteady aerodynamics of rotating systems

CFD validation

Aeroacoustic phenomena



For inquiry contact us for a quote.

DESIGN & ENGINEERING SERVICES

We offer measurement solutions and services all from one source

Design to customers specification or CAD

Heat transfer, structural, frequency and CFD analysis

Integration of probes, and sensors into existing test rigs

Procurement of all necessary parts

Commissioning and testing support

Test planning and conduction software and support



For inquiry contact us for a quote.
